How to Bind GridView with jQuery AJAX Step by Step – No Page Postback

How to Bind GridView with jQuery AJAX Step by Step – No Page Postback

In this Tutorial I will teach you with example how to bind a GridView with jQuery AJAX, from data which is fetched from a Database. The GridView will also have pagination and the whole thing – from binding to paging will work in asynchronous manner (without PostBack).

I will Bind GridView from Database

The binding process of GridView needs data that will come from a Database table. For this example I am using a Products Table which looks like this:

products table

I am providing you the Script for this table which you can run on your SQL Server and it will create this table with some 70+ records.

The Script is:

SET ANSI_NULLS ON
GO
SET QUOTED_IDENTIFIER ON
GO
CREATE TABLE [dbo].[Products](
    [ProductID] [int] IDENTITY(1,1) NOT NULL,
    [ProductName] [nvarchar](40) NOT NULL,
    [SupplierID] [int] NULL,
    [CategoryID] [int] NULL,
    [QuantityPerUnit] [nvarchar](20) NULL,
    [UnitPrice] [money] NULL,
    [UnitsInStock] [smallint] NULL,
    [UnitsOnOrder] [smallint] NULL,
    [ReorderLevel] [smallint] NULL,
    [Discontinued] [bit] NOT NULL,
 CONSTRAINT [PK_Products] PRIMARY KEY CLUSTERED
(
    [ProductID] ASC
)WITH (PAD_INDEX = OFF, STATISTICS_NORECOMPUTE = OFF, IGNORE_DUP_KEY = OFF, ALLOW_ROW_LOCKS = ON, ALLOW_PAGE_LOCKS = ON) ON [PRIMARY]
) ON [PRIMARY]

GO
SET IDENTITY_INSERT [dbo].[Products] ON

GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (1, N'Chai', 1, 1, N'10 boxes x 20 bags', 18.0000, 39, 0, 10, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (2, N'Chang', 1, 1, N'24 - 12 oz bottles', 19.0000, 17, 40, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (3, N'Aniseed Syrup', 1, 2, N'12 - 550 ml bottles', 10.0000, 13, 70, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (4, N'Chef Anton''s Cajun Seasoning', 2, 2, N'48 - 6 oz jars', 22.0000, 53, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (5, N'Chef Anton''s Gumbo Mix', 2, 2, N'36 boxes', 21.3500, 0, 0, 0, 1)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (6, N'Grandma''s Boysenberry Spread', 3, 2, N'12 - 8 oz jars', 25.0000, 120, 0, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (7, N'Uncle Bob''s Organic Dried Pears', 3, 7, N'12 - 1 lb pkgs.', 30.0000, 15, 0, 10, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (8, N'Northwoods Cranberry Sauce', 3, 2, N'12 - 12 oz jars', 40.0000, 6, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (9, N'Mishi Kobe Niku', 4, 6, N'18 - 500 g pkgs.', 97.0000, 29, 0, 0, 1)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (10, N'Ikura', 4, 8, N'12 - 200 ml jars', 31.0000, 31, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (11, N'Queso Cabrales', 5, 4, N'1 kg pkg.', 21.0000, 22, 30, 30, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (12, N'Queso Manchego La Pastora', 5, 4, N'10 - 500 g pkgs.', 38.0000, 86, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (13, N'Konbu', 6, 8, N'2 kg box', 6.0000, 24, 0, 5, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (14, N'Tofu', 6, 7, N'40 - 100 g pkgs.', 23.2500, 35, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (15, N'Genen Shouyu', 6, 2, N'24 - 250 ml bottles', 15.5000, 39, 0, 5, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (16, N'Pavlova', 7, 3, N'32 - 500 g boxes', 17.4500, 29, 0, 10, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (17, N'Alice Mutton', 7, 6, N'20 - 1 kg tins', 39.0000, 0, 0, 0, 1)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (18, N'Carnarvon Tigers', 7, 8, N'16 kg pkg.', 62.5000, 42, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (19, N'Teatime Chocolate Biscuits', 8, 3, N'10 boxes x 12 pieces', 9.2000, 25, 0, 5, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (20, N'Sir Rodney''s Marmalade', 8, 3, N'30 gift boxes', 81.0000, 40, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (21, N'Sir Rodney''s Scones', 8, 3, N'24 pkgs. x 4 pieces', 10.0000, 3, 40, 5, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (22, N'Gustaf''s Knäckebröd', 9, 5, N'24 - 500 g pkgs.', 21.0000, 104, 0, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (23, N'Tunnbröd', 9, 5, N'12 - 250 g pkgs.', 9.0000, 61, 0, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (24, N'Guaraná Fantástica', 10, 1, N'12 - 355 ml cans', 4.5000, 20, 0, 0, 1)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (25, N'NuNuCa Nuß-Nougat-Creme', 11, 3, N'20 - 450 g glasses', 14.0000, 76, 0, 30, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (26, N'Gumbär Gummibärchen', 11, 3, N'100 - 250 g bags', 31.2300, 15, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (27, N'Schoggi Schokolade', 11, 3, N'100 - 100 g pieces', 43.9000, 49, 0, 30, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (28, N'Rössle Sauerkraut', 12, 7, N'25 - 825 g cans', 45.6000, 26, 0, 0, 1)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (29, N'Thüringer Rostbratwurst', 12, 6, N'50 bags x 30 sausgs.', 123.7900, 0, 0, 0, 1)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (30, N'Nord-Ost Matjeshering', 13, 8, N'10 - 200 g glasses', 25.8900, 10, 0, 15, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (31, N'Gorgonzola Telino', 14, 4, N'12 - 100 g pkgs', 12.5000, 0, 70, 20, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (32, N'Mascarpone Fabioli', 14, 4, N'24 - 200 g pkgs.', 32.0000, 9, 40, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (33, N'Geitost', 15, 4, N'500 g', 2.5000, 112, 0, 20, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (34, N'Sasquatch Ale', 16, 1, N'24 - 12 oz bottles', 14.0000, 111, 0, 15, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (35, N'Steeleye Stout', 16, 1, N'24 - 12 oz bottles', 18.0000, 20, 0, 15, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (36, N'Inlagd Sill', 17, 8, N'24 - 250 g  jars', 19.0000, 112, 0, 20, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (37, N'Gravad lax', 17, 8, N'12 - 500 g pkgs.', 26.0000, 11, 50, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (38, N'Côte de Blaye', 18, 1, N'12 - 75 cl bottles', 263.5000, 17, 0, 15, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (39, N'Chartreuse verte', 18, 1, N'750 cc per bottle', 18.0000, 69, 0, 5, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (40, N'Boston Crab Meat', 19, 8, N'24 - 4 oz tins', 18.4000, 123, 0, 30, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (41, N'Jack''s New England Clam Chowder', 19, 8, N'12 - 12 oz cans', 9.6500, 85, 0, 10, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (42, N'Singaporean Hokkien Fried Mee', 20, 5, N'32 - 1 kg pkgs.', 14.0000, 26, 0, 0, 1)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (43, N'Ipoh Coffee', 20, 1, N'16 - 500 g tins', 46.0000, 17, 10, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (44, N'Gula Malacca', 20, 2, N'20 - 2 kg bags', 19.4500, 27, 0, 15, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (45, N'Rogede sild', 21, 8, N'1k pkg.', 9.5000, 5, 70, 15, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (46, N'Spegesild', 21, 8, N'4 - 450 g glasses', 12.0000, 95, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (47, N'Zaanse koeken', 22, 3, N'10 - 4 oz boxes', 9.5000, 36, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (48, N'Chocolade', 22, 3, N'10 pkgs.', 12.7500, 15, 70, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (49, N'Maxilaku', 23, 3, N'24 - 50 g pkgs.', 20.0000, 10, 60, 15, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (50, N'Valkoinen suklaa', 23, 3, N'12 - 100 g bars', 16.2500, 65, 0, 30, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (51, N'Manjimup Dried Apples', 24, 7, N'50 - 300 g pkgs.', 53.0000, 20, 0, 10, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (52, N'Filo Mix', 24, 5, N'16 - 2 kg boxes', 7.0000, 38, 0, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (53, N'Perth Pasties', 24, 6, N'48 pieces', 32.8000, 0, 0, 0, 1)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (54, N'Tourtière', 25, 6, N'16 pies', 7.4500, 21, 0, 10, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (55, N'Pâté chinois', 25, 6, N'24 boxes x 2 pies', 24.0000, 115, 0, 20, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (56, N'Gnocchi di nonna Alice', 26, 5, N'24 - 250 g pkgs.', 38.0000, 21, 10, 30, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (57, N'Ravioli Angelo', 26, 5, N'24 - 250 g pkgs.', 19.5000, 36, 0, 20, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (58, N'Escargots de Bourgogne', 27, 8, N'24 pieces', 13.2500, 62, 0, 20, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (59, N'Raclette Courdavault', 28, 4, N'5 kg pkg.', 55.0000, 79, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (60, N'Camembert Pierrot', 28, 4, N'15 - 300 g rounds', 34.0000, 19, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (61, N'Sirop d''érable', 29, 2, N'24 - 500 ml bottles', 28.5000, 113, 0, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (62, N'Tarte au sucre', 29, 3, N'48 pies', 49.3000, 17, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (63, N'Vegie-spread', 7, 2, N'15 - 625 g jars', 43.9000, 24, 0, 5, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (64, N'Wimmers gute Semmelknödel', 12, 5, N'20 bags x 4 pieces', 33.2500, 22, 80, 30, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (65, N'Louisiana Fiery Hot Pepper Sauce', 2, 2, N'32 - 8 oz bottles', 21.0500, 76, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (66, N'Louisiana Hot Spiced Okra', 2, 2, N'24 - 8 oz jars', 17.0000, 4, 100, 20, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (67, N'Laughing Lumberjack Lager', 16, 1, N'24 - 12 oz bottles', 14.0000, 52, 0, 10, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (68, N'Scottish Longbreads', 8, 3, N'10 boxes x 8 pieces', 12.5000, 6, 10, 15, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (69, N'Gudbrandsdalsost', 15, 4, N'10 kg pkg.', 36.0000, 26, 0, 15, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (70, N'Outback Lager', 7, 1, N'24 - 355 ml bottles', 15.0000, 15, 10, 30, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (71, N'Flotemysost', 15, 4, N'10 - 500 g pkgs.', 21.5000, 26, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (72, N'Mozzarella di Giovanni', 14, 4, N'24 - 200 g pkgs.', 34.8000, 14, 0, 0, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (73, N'Röd Kaviar', 17, 8, N'24 - 150 g jars', 15.0000, 101, 0, 5, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (74, N'Longlife Tofu', 4, 7, N'5 kg pkg.', 10.0000, 4, 20, 5, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (75, N'Rhönbräu Klosterbier', 12, 1, N'24 - 0.5 l bottles', 7.7500, 125, 0, 25, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (76, N'Lakkalikööri', 23, 1, N'500 ml', 18.0000, 57, 0, 20, 0)
GO
INSERT [dbo].[Products] ([ProductID], [ProductName], [SupplierID], [CategoryID], [QuantityPerUnit], [UnitPrice], [UnitsInStock], [UnitsOnOrder], [ReorderLevel], [Discontinued]) VALUES (77, N'Original Frankfurter grüne Soße', 12, 2, N'12 boxes', 13.0000, 32, 0, 15, 0)
GO
SET IDENTITY_INSERT [dbo].[Products] OFF
GO

I will also need a Stored Procedure which will fetch the records from this Products table. The procedure implements Custom Paging which fetches the records of only the current Page.

It takes up 2 parameters – the page number and the page size, and then returns the records of only the selected page.

This Stored Procedure is given below:

CREATE PROCEDURE [dbo].[sp_GetProductByCustomPaging]
    @PageNo     INT,
    @pageSize   INT
AS
BEGIN
    DECLARE @qry  NVARCHAR(1000);
    SET @qry='SELECT * FROM (SELECT ROW_NUMBER() OVER (ORDER BY ProductID DESC) AS ''RowNum'',* FROM Products WHERE 1=1) a WHERE a.RowNum BETWEEN ('+CAST(@pageNo AS NVARCHAR(5))+'-1)*'+CAST(@pageSize AS NVARCHAR(5))+'+1 AND ('+CAST(@pageNo AS NVARCHAR(5))+'*'+CAST(@pageSize AS NVARCHAR(5))+')'
    SET @qry=@qry+';SELECT Count(*) As ''Total'' From Products'
    EXEC Sp_executesql @qry
END
You can learn how Custom Paging works and why it speeds up the performance of a web page, in my tutorial on Custom Paging in SQL Server.

The GridView Code

With the database part ready let us build the GridView. First add the GridView in your .aspx page like this:

<div id="content">
    <asp:GridView ID="gridView" runat="server" AutoGenerateColumns="false">
        <Columns>
            <asp:BoundField DataField="RowNum" HeaderText="RowNum" />
            <asp:BoundField DataField="ProductName" HeaderText="ProductName" />
            <asp:BoundField DataField="QuantityPerUnit" HeaderText="QuantityPerUnit" />
            <asp:BoundField DataField="UnitPrice" HeaderText="UnitPrice" />
            <asp:BoundField DataField="UnitsInStock" HeaderText="UnitsInStock" />
        </Columns>
    </asp:GridView>
    <div id="pagingDiv"></div>
    <img id="loadingImg" src="loading.gif" />
    <asp:Button ID="submitButton" Text="Bind GridView" runat="server" />
</div>
  • To make the example simple I am binding the GridView to only with the 4 columns of the Products table.
  • Here the pagingDiv is the div control where the paging links for this GridView will be created.
  • The loadingImg is a loading gif image that will show up whenever the AJAX call is under process.
  • The button there is for binding the GridView with jQuery AJAX. The Click event of this button will start the binding process.
Now add the below code to the .aspx.cs page:
protected void Page_Load(object sender, EventArgs e)
{
    if (!IsPostBack)
    {
        BindDummyRow();
    }
}

private void BindDummyRow()
{
    DataTable dummy = new DataTable();
    dummy.Columns.Add("RowNum");
    dummy.Columns.Add("ProductName");
    dummy.Columns.Add("QuantityPerUnit");
    dummy.Columns.Add("UnitPrice");
    dummy.Columns.Add("UnitsInStock");
    dummy.Rows.Add();
    gridView.DataSource = dummy;
    gridView.DataBind();
}

[WebMethod]
public static string bind(string pageNo)
{
    SqlConnection conn = new SqlConnection();
    SqlCommand cmd = new SqlCommand();
    DataSet dataSet = new DataSet();

    conn.ConnectionString = ConfigurationManager.ConnectionStrings["CS"].ConnectionString;
    cmd.Connection = conn;

    cmd.CommandType = CommandType.StoredProcedure;
    cmd.CommandText = "sp_GetProductByCustomPaging";
    cmd.Parameters.AddWithValue("@PageNo", pageNo);
    cmd.Parameters.AddWithValue("@pageSize", 10);

    SqlDataAdapter sqlDataAdapter = new SqlDataAdapter();
    sqlDataAdapter.SelectCommand = cmd;
    sqlDataAdapter.Fill(dataSet);
    return dataSet.GetXml();
}
  • Here I am binding the GridView, on the aspx.cs page, with an empty table on the Page_Load event.
  • The [WebMethod] bind() function will fetch the records from the Products table. This function will be called by the jQuery code in the .aspx page.
  • The bind() function will fill the records into the DataSet then return these records in an XML format.
  • Since the bind() function is called by jQuery therefore there will not be any page PostBack.
If you are thinking about how the C# function can be called by jQuery then please read my tutorial on jQuery AJAX method that will provide you a good and detailed knowledge on this concept.

The jQuery Code

Let’s move towards the most important part which is the jQuery code, it will not only perform the binding of the GridView but also create it’s paging.

In your .aspx page first give the reference of jQuery just above the ending body tag:

<script src="https://ajax.googleapis.com/ajax/libs/jquery/3.1.0/jquery.min.js"></script>

After that create another script tag with document .ready() function. Inside the .ready() function the jQuery codes will be added:

<script type="text/javascript">
    $(document).ready(function () {
       //jquery codes
    });
</script>
Now coming to the jQuery codes

Add .ajaxStart() and .ajaxStop() events. These events will show and hide the loading image.

$(document).ajaxStart(function () {
    $("#loadingImg").show();
});

$(document).ajaxStop(function () {
    $("#loadingImg").hide();
});

Next add the button click event. Here I call another function called CallServerFunction() and pass ‘1’ to it’s parameter.

This specifies that I want to Bind the GridView with the first page records.

I return false to prevent the page from PostBack.

$("#submitButton").click(function (e) {
    CallServerFunction(1);
    return false;
});

Moving to the CallServerFunction() which does the jQuery AJAX call. This .ajax() will call the C# function called bind(). It also passes the page number to it’s parameter.

function CallServerFunction(pageNo) {
    $.ajax({
        type: "POST",
        url: "index.aspx/bind",
        data: "{pageNo:" + pageNo + "}",
        contentType: "application/json; charset=utf-8",
        dataType: "json",
        success: function (result, status, xhr) {
            OnSuccess(msg.d, pageNo);
        },
        error: function (req, status, error) {
            alert(req + " " + status + " " + error);
        }
    });
}

Now add the OnSuccess function which is called when the jQuery AJAX request completes successfully.

The OnSuccess() function gets the returned XML value and the current page number.

function OnSuccess(message, pageNo) {
    var xmlDoc = $.parseXML(message);
    var xml = $(xmlDoc);
    var product = xml.find("Table");
    var row = $("[id*=gridView] tr:last-child").clone(true);
    $("[id*=gridView] tr").not($("[id*=gridView] tr:first-child")).remove();

    $.each(product, function () {
        var customer = $(this);
        $("td", row).eq(0).html($(this).find("RowNum").text());
        $("td", row).eq(1).html($(this).find("ProductName").text());
        $("td", row).eq(2).html($(this).find("QuantityPerUnit").text());
        $("td", row).eq(3).html($(this).find("UnitPrice").text());
        $("td", row).eq(4).html($(this).find("UnitsInStock").text());
        $("[id*=gridView]").append(row);
        row = $("[id*=gridView] tr:last-child").clone(true);
    });

    var result = Paging(pageNo, 10, xml.find("Table1 > Total").text(), "myClass", "myDisableClass");
    $("#pagingDiv").html(result)
}
  • From the XML which the OnSuccess() function gets, it extracts the values of the records by looping through them.
  • It then adds these values to the empty GridView control.
  • The looping through the XML is done with jQuery Each method.
  • After looping, it call the Paging() function.
  • The XML node called Total contains the total number of records on the database table. The ‘Total’ node is contained inside the Table1 node and I use .find(“Table1 > Total”).text() to get it’s value.
  • The Paging function creates the pagination links for the GridView control.
  • The pagination links are displayed on the pagingDiv element.

In this way the binding process of GridView is done with jQuery AJAX.

I have written a complete tutorial on creating paging links with jQuery which you can read at jQuery Pagination. Also learn how the jQuery Find method works which will be very useful for you when working with jQuery.

Next, add the Paging() function to your jQuery code:

function Paging(PageNumber, PageSize, TotalRecords, ClassName, DisableClassName) {
    var ReturnValue = "";

    var TotalPages = Math.ceil(TotalRecords / PageSize);
    if (+PageNumber > 1) {
        if (+PageNumber == 2)
            ReturnValue = ReturnValue + "<a pn='" + (+PageNumber - 1) + "' class='" + ClassName + "'>Previous</a>   ";
        else {
            ReturnValue = ReturnValue + "<a pn='";
            ReturnValue = ReturnValue + (+PageNumber - 1) + "' class='" + ClassName + "'>Previous</a>   ";
        }
    }
    else
        ReturnValue = ReturnValue + "<span class='" + DisableClassName + "'>Previous</span>   ";
    if ((+PageNumber - 3) > 1)
        ReturnValue = ReturnValue + "<a pn='1' class='" + ClassName + "'>1</a> ..... | ";
    for (var i = +PageNumber - 3; i <= +PageNumber; i++)
        if (i >= 1) {
            if (+PageNumber != i) {
                ReturnValue = ReturnValue + "<a pn='";
                ReturnValue = ReturnValue + i + "' class='" + ClassName + "'>" + i + "</a> | ";
            }
            else {
                ReturnValue = ReturnValue + "<span style='font-weight:bold;'>" + i + "</span> | ";
            }
        }
    for (var i = +PageNumber + 1; i <= +PageNumber + 3; i++)
        if (i <= TotalPages) {
            if (+PageNumber != i) {
                ReturnValue = ReturnValue + "<a pn='";
                ReturnValue = ReturnValue + i + "' class='" + ClassName + "'>" + i + "</a> | ";
            }
            else {
                ReturnValue = ReturnValue + "<span style='font-weight:bold;'>" + i + "</span> | ";
            }
        }
    if ((+PageNumber + 3) < TotalPages) {
        ReturnValue = ReturnValue + "..... <a pn='";
        ReturnValue = ReturnValue + TotalPages + "' class='" + ClassName + "'>" + TotalPages + "</a>";
    }
    if (+PageNumber < TotalPages) {
        ReturnValue = ReturnValue + "   <a pn='";
        ReturnValue = ReturnValue + (+PageNumber + 1) + "' class='" + ClassName + "'>Next</a>";
    }
    else
        ReturnValue = ReturnValue + "   <span class='" + DisableClassName + "'>Next</span>";

    return (ReturnValue);
}

The last thing is to add the click events on the anchor tags inside the pagination links:

$("#pagingDiv").on("click", "a", function () {
    CallServerFunction($(this).attr("pn"));
});

On clicking the anchor tags the GridView is bind with new page values.

Add the CSS to the Page

You should also add the below CSS to your page. This will style not only the GridView but also the paging links:

<style>
    #content {
        position: relative;
        border: dashed 2px #CCC;
    }

        #content #loadingImg {
            display: none;
            position: absolute;
            margin: auto;
            top: 0;
            left: 0;
            right: 0;
            bottom: 0;
        }

        #content #gridView {
            background-color: purple;
        }

            #content #gridView tr th {
                background-color: #CCC;
            }

        #content #submitButton {
            margin: 10px;
        }

    #pagingDiv {
        padding: 15px 0;
    }

        #pagingDiv .myDisableClass {
            background-color: #4CAF50;
        }

        #pagingDiv .myClass {
            background-color: #ebbebe;
        }

        #pagingDiv a, #pagingDiv span {
            display: inline-block;
            padding: 0px 9px;
            margin-right: 4px;
            border-radius: 3px;
            border: solid 1px #c0c0c0;
            background: #e9e9e9;
            box-shadow: inset 0px 1px 0px rgba(255,255,255, .8), 0px 1px 3px rgba(0,0,0, .1);
            font-size: .875em;
            font-weight: bold;
            text-decoration: none;
            color: #717171;
            text-shadow: 0px 1px 0px rgba(255,255,255, 1);
        }

            #pagingDiv a:hover {
                cursor: pointer;
                background: #fefefe;
                background: -webkit-gradient(linear, 0% 0%, 0% 100%, from(#FEFEFE), to(#f0f0f0));
                background: -moz-linear-gradient(0% 0% 270deg,#FEFEFE, #f0f0f0);
            }

            #pagingDiv a.active {
                border: none;
                background: #616161;
                box-shadow: inset 0px 0px 8px rgba(0,0,0, .5), 0px 1px 0px rgba(255,255,255, .8);
                color: #f0f0f0;
                text-shadow: 0px 0px 3px rgba(0,0,0, .5);
            }

        #pagingDiv span {
            color: #f0f0f0;
            background: #616161;
        }
</style>
Screenshot of the GridView

See this is how the GridView will look when it is bind with the data by using the jQuery AJAX method.

jquery ajax gridview

Check the below important link:

DOWNLOAD

SHARE THIS ARTICLE

  • linkedin
  • reddit
yogihosting

ABOUT THE AUTHOR

I hope you enjoyed reading this tutorial. If it helped you then consider buying a cup of coffee for me. This will help me in writing more such good tutorials for the readers. Thank you. Buy Me A Coffee donate
